Description
Basic function
| Measure mode | range | resolution | Basic accuracy |
| Ground resistance | 20Ω | 0.01Ω | ±(2%+0.1Ω) |
| 200Ω | 0.1Ω | ±(2%+3dgt) | |
| 2000Ω | 1Ω | ||
| Ground current ( AC current) | 200V | 0.1V | ±(2.0%+6dgt) |
General features
| Display | 84.8×59.8mm LCD display, max display “1999”. |
| Over range presentation | it will display “1”on the top number when it is over range |
| Power | alkalescence battery LR (1.5V)×8(can contact with power adapter)when the battery is low, it will display a low battery sign |
| Power Dissipation | Electricity cost during test<=800mw |
| Work environment | Teperature 0-40 ; relative humidity 30%-80%RH |
| Product size | 175(L)×110(W)×70(D)mm |
| Weight | Approx : 680g(include battery) |
