Description

Specification

Model : LX-101A
Brand : Lutron
Origin : Taiwan
Circuit : Custom one-chip of microprocessor LSI
Display : LCD Size : 44 mm × 29 mm. Dual Function LCD display

Light Meter :
Range : Auto range 0 to 50,000 LUX
Unit: LUX
Sensor : The Exclusive photo Diode & Color Correction filter, Spectrum meet C.I.E.
Zero Adjustment : External adjustment by pushing button

Over Indication : Show
Data Hold : Freeze the display reading
Sampling Time of Display : Approx. 1 second.
Power off : Manual off by push button.
Operating Temperature : 0 to 50 ℃.
Operating Humidity : Less than 80% R.H.
Power Supply : 006P DC 9V battery (Alkaline or Heavy Duty Type )
Power Current : Approx. DC 5 mA
Weight : 278 g/ 0.61 LB
Dimension Meter : ( 135 × 60 ×  33 ) mm
Dimension Light Probe : ( 82 ×  55 × 7 ) mm
Accessories Included : Instruction Manual (1 PC), Light Probe (1 PC)
Optional Accessories: Carrying Cas, CA-52A
Warranty : One Year Service Warranty
After-sales service provided : Free service

Features:

• Built-in Low Battery Indicator
• LCD Display Provides Low Power Consumption
• 2000/20,000/50,000 Lux, Auto range,
• Light Sensor Used the exclusive photo diode & Color Correction Filter, Spectrum Meet C.I.E
• Light Sensor cosine correction factor meet standard
• Separate Light Sensor allows user to measure the light at an optimum position
• Zero Key Function
• Microprocessor Circuit
• DC 9V battery (006 P )
• Provides High Accuracy

Benefits

• Accurate Light Measurement – Provides precise Lux readings, ensuring optimal lighting conditions.
• Easy to Use – The user-friendly interface allows effortless operation, even for beginners.
• Portable & Compact – Its lightweight design makes it convenient for field measurements.
• Energy Efficiency – Helps optimize lighting efficiency, reducing unnecessary energy consumption.
• Durability – Built with high-quality materials to ensure long-lasting performance.
• Data Hold Function – Enables users to freeze readings for easy data recording.
• Wide Measurement Range – Covers a broad Lux range, accommodating different lighting conditions.
• Cost-Effective – Offers high precision at an affordable price point.

Advantages

• High Sensitivity Sensor – Detects even minimal changes in light intensity.
• Fast Response Time – Provides real-time Lux readings without delays.
• Battery Operated – Ensures portability and can be used in various locations.
• Clear Display – LCD screen ensures readability in different lighting environments.
• Versatile Use – Suitable for multiple applications across different industries.

Applications

• Photography & Videography – Ensures optimal lighting conditions for professional shoots.
• Industrial & Workplace Safety – Helps maintain appropriate lighting in factories and offices.
• Agriculture & Horticulture – Used for measuring light intensity to improve plant growth.
• Educational & Laboratory Use – Essential for scientific experiments and research.
• Interior & Architectural Design – Assists in creating well-lit environments.
• Quality Control & Inspection – Ensures compliance with lighting standards in production facilities.
